1206-0011
Model: 1206M
Double Acting Cable Cylinder with power stroke in both directions, 2.0 inch bore, heavy duty w/ piston magnet.
- Maximum pressure: 500 PSI
- Operating temperature range: 20º to 140º F.
- Adjustable cushions
- Mounting interchangeable with T-O-M Brand Model CC52
Attributes
| Model | 1206M |
| Bore, in. | 2.0 |
| Eff. Area, in.sq | 3.09 |
| Force@500 PSI, lbs. | 1545 |
| Option(s) | 500 PSI, Piston Magnet |
Click image to enlarge
